AGNES RF is an advanced radiofrequency microneedling system developed by a Korean dermatologist. It allows for precise treatment of targeted fat deposits and skin conditions using patented insulated needles and monopolar RF energy. The device enables selective tissue coagulation, collagen remodeling, and skin tightening with minimal downtime and high safety.
Clinicians can tailor treatments for each patient using various needle configurations and precise depth control, achieving predictable outcomes for facial contouring and rejuvenation.
AGNES delivers monopolar radiofrequency energy at 1 MHz using insulated microneedles. These needles target either the dermis or subcutaneous fat layer, depending on the treatment objective.
Insulated needle shafts protect the epidermis while the exposed tips deliver focused RF energy.
The square waveform of the RF signal ensures stable and uniform energy delivery, minimizing thermal spread and risk to surrounding tissue.
Thermal coagulation of fat cells leads to a gradual reduction in localized fat deposits.
Simultaneous collagen stimulation supports firmer, rejuvenated skin over time.
AGNES is suitable for precision treatments on the face, including delicate areas such as under the eyes, the jawline, and nasolabial folds.
Patented insulated microneedles: Targeted RF delivery with minimal risk to surface skin
1 MHz monopolar RF output: Ideal for both fat coagulation and skin rejuvenation
Square waveform: Provides consistent energy distribution
Multiple needle types: For treating different skin depths and concerns
Built-in safety system: Protects against needle errors and overheating
Minimal downtime: Most patients resume daily activities within a day or two
| Item | Description | Item | Description |
|---|---|---|---|
| Applied Energy | RF(Radio Frequency) - 1MHz | Camera | 1.3 Mega pixel CMOS |
| Display | 10.1 inch LCD touch panel | Power Supply | AC 100V~250V, 50/60Hz, 280VA |
| Dimensions | (W)290mm x (D)455m x (H)271.7mm | Handpiece Type | Mono-polar Handpiece Bi-polar handpiece |
| Tip | Microblade Pin(Single use) | Handpiece Type | Mono-polar Handpiece Bi-polar handpiece |
| Wave form | Square wave | Weight | 5.85Kg |
AGNES offers 9 types of polygonal (insulated) blade pins, each designed for specific indications and depths. These microneedles enable practitioners to perform customized treatments for:
Eye bags (periorbital fat)
Double chin (submental fat)
Jawline and jowl contouring
Nasolabial folds and marionette lines
Localized acne and sebaceous gland ablation
Each needle type has a different length and configuration (e.g., single-pin or three-pin), allowing precise control over the depth and energy delivery to suit the treatment area.
There are nine needles differing in size and amount of insulation. Using the results of multiple clinical studies, the length of insulation on each needle has been calculated, down to the millimeter, to successfully treat different areas.
AGNES three-pin F3A Micro Blade Pin is engineered so that the non-insulated tip of the needles are able to coagulate the subcutaneous layer (fat) and/or other sub-dermis layers depending on the different angles of insertion. The 2.00mm insulated portion of the needle, closer to the shoulder, protects the outer layer of the skin from thermal energy outputs. The three-pin needles are designed for skin and fat coagulation to enhance facial volume reduction procedures.
This carefully calculated length and placement of insulation differ on every needle AGNES RF utilizes, giving a wide range of efficient, precise, and safe treatment possibilities.
As illustrated, the areas and length of micro-insulation of the AGNES RF needles have been engineered to protect the outer layers of skin even through different angles of insertion. As the angles of insertion change, the length of penetration changes, allowing the user to coagulate and tighten within different depths of the subcutaneous layer.
Agnes is the best RF microneedling device for energy utilization. The reactions in the tissue are better with Agnes RF over other RF microneedling devices. The multipolar needle configuration comprises a single-pin or three-pin needle as an application electrode. These needles are partially insulated to protect the other tissues.
Agnes Radio Frequency burns fat pockets from the face, jawline, neck, and any other areas of the body.
Yes. The Agnes RF device was originally made to treat acne but now it can also be used to improve the contours of the face.
It has no effect on the skin depending on the type.
Choose the best professional microneedling machine based on your needs.
Agnes Radio Frequency microneedling machine is one of its kind with a single-pin or three-pin insulated needle as an application electrode. No other RF microneedling device uses this.
Trained healthcare professionals can use the microneedling device like –
Introducing AGNES Product
